![Figure 3 – Base material strength analysis The dashboard is composed of various JMP platforms: Graph Builder, Distributions and ANOVA. The custom map shape[1] of the Graph Builder displays the two samples corresponding to each of the two plates and the position of the various cupping tests colored by strength. In the ANOVA, the overlap of the two diamond tips demonstrates that the plate can be considered as identical. The chart on the right shows that the strength variance is higher on operator side (OS). Once aggregated, data from the bottom distribution presents an average strength is 9.76±0.18 tons (at 2σ).](/t5/image/serverpage/image-id/43959i2840B4032B97DD96/image-size/tiny/is-moderation-mode/true?v=v2&px=100 "2022-07-14_16-57-21.700.png")
![Figure 3 – Base material strength analysis The dashboard is composed of various JMP platforms: Graph Builder, Distributions and ANOVA. The custom map shape[1] of the Graph Builder displays the two samples corresponding to each of the two plates and the position of the various cupping tests colored by strength. In the ANOVA, the overlap of the two diamond tips demonstrates that the plate can be considered as identical. The chart on the right shows that the strength variance is higher on operator side (OS). Once aggregated, data from the bottom distribution presents an average strength is 9.76±0.18 tons (at 2σ).](/t5/image/serverpage/image-id/43960i481DEB136F7CBAA4/image-size/tiny/is-moderation-mode/true?v=v2&px=100 "image.png")
Added
07-14-2022
05:33 PM
Figure 4 – Appearance of the plate – The plates present a relatively flat aspect on the drive side and waves on the operator side. The history of the plates is unknown but there must have been a rolling of planishing issue with a higher force applied on the operator side, which created this appearance and a periodic modification of the strength.
